Remote Release · Safer Lifting · Automation Ready

The Automatic Uncoupling Device is an intelligent lifting attachment designed for remote load release and automated material handling operations. It allows operators to open and release the hook remotely, reducing the need for personnel to approach suspended loads or enter hazardous lifting areas.

The device can be operated independently via an industrial remote controller or integrated with cranes, automated travelling cranes and material handling systems through an optional PLC control module.

Standard lifting capacities include 3T, 5T, 10T and 20T, with higher-capacity and customized configurations available for specific applications.

Product Overview

The Automatic Uncoupling Device provides a safer and more efficient alternative to conventional manual hook release.

During traditional lifting operations, personnel may need to approach the load to manually disconnect the hook after positioning. In heavy-duty, high-temperature, high-dust or automated environments, this can increase both operational risk and handling time.

With remote-controlled hook opening, the Automatic Uncoupling Device helps minimize manual intervention while improving lifting efficiency. It can also be integrated into automated crane systems, making it suitable for both conventional industrial lifting and unmanned or semi-automated material handling applications.

Key Features & Benefits

Remote Automatic Release

The hook can be opened remotely using an industrial remote controller, allowing operators to release the load from a safer working distance without manually approaching the lifting point.

Improved Operational Safety

By reducing the need for personnel to work close to suspended loads, heavy components or hazardous operating areas, the system helps improve safety during lifting and unloading operations.

Higher Handling Efficiency

Remote hook release eliminates unnecessary manual unhooking procedures, helping shorten handling cycles in repetitive and high-frequency lifting operations.

Automation Ready

An optional PLC control module enables integration with automated cranes, travelling cranes, production lines and material handling systems.

Multiple Lifting Capacities

Standard models are available in: 3T · 5T · 10T · 20T

Higher lifting capacities, including 25T, 32T, 40T and other customized capacities, can be engineered according to specific project requirements. 脱钩器画册 （中英）

Flexible Configurations

Different lifting point structures, hook types, control systems and optional modules are available to meet various operating conditions.

System Composition

The Automatic Uncoupling System mainly consists of three components:

Automatic Uncoupling Device

The main lifting and hook release unit, designed to perform the mechanical opening and closing functions.

Industrial Remote Controller

Allows the operator to remotely control hook opening and release operations from a safe working position.

PLC Control Module — Optional

Enables the device to communicate with automated crane systems and external control systems for integrated lifting and material handling operations.

Depending on the application, optional weighing modules, magnetic hook modules and multi-device control configurations are also available.

How It Works

The Automatic Uncoupling Device is installed between the lifting equipment and the load.

Once the load has been lifted, transported and positioned at the designated location, the operator can send a release command using the industrial remote controller. The device then opens the hook, allowing the load to be released without manual unhooking.

For automated applications, the optional PLC control module can receive external control signals and coordinate the release operation with crane movements, load positioning and production processes.

Lifting → Transporting → Positioning → Remote Release

This operating principle makes the device particularly suitable for applications requiring remote operation, reduced manual intervention and automated material handling.
